■ SPECIFICATIONS

Tape width Max 56mm Tape Thickness 0.25 ~ 0.5mm Tape Material PS, PVC, PET, PC Machine Control PLC & LCD Touch Panel Unwinder Section 3 inch bobbin inside diameter 540mm outside diamerter (Max) Vision System Option Heater 250W X 4 Cartridge Heater & PID Temp Control Mold Assembly By Compressed Air (With vacuum option) Punch Assembly By Press Punching System Slit By Rotory Cutting System Winder 600mm Outside Diameter (Max) X 2Winder Main Driver Warm Geard Motor 0.75Kw By Inverter Control Dimension 2250(L) X 875(W) X 1600(H)mm Machine Weight 650Kg Utility Compressed Air : 5Kg/cm Above Consuption Volume : 100NL/min Power Source : AC 200 ~ 220V (3phase) 50 ~ 60Hz Machine Speed Max 48mm feeding : 172m/hr Max 64mm feeding : 230m/hr
